GVG80 Vacuum Glass Window

▲Aluminum Profile Thickness:1.8mm

▲Frame Width:80mm

▲Sash&Window Width:87mm

▲Visibal Frame Width:36mm

▲Thermal Break Width:35.3mm

▲Glass:24-39mm

▲Euro-slot profile design

▲Uw Less than or equal to 1.1 W/㎡ · k

The scientific and rational design of our window&door systems considers human-centric design and energy conservation.The appearance styles are rich and various,with comprehensive fuctions,standardized processes,universal hardware components and complete accessories.We select suitable door and window products for clients,providing systemactic solutions.

The advantages of our GVG80 vacuum glass window for passive house are following for your reference.

GVG90 vacuum glass window has exceptional thermal insulation capabilities,effectively minimizing temperature float in seasonal weather conditions and maintaining stable indoor temperatures inside rooms.This results in reduced energy consumption and the creation of a comfortable living environment.

Long Life-Span

By installing vacuum glass products,our clients will effectively extend the lifespan of window frames,ensuring their durability along with high-quality visibility standards.

Finally,it uses our vacuum insulated glass units and also our thicker vacuum solar glass units,and secretly houses the associated electrical wiring with a side feed for your supply,when solar is required.Priced to compete with triple glazed good quality aluminium windows,there is only one choice,that is our GVG80 vacuum glass window for passive house.

▲Thermal Insulation:Level 9-10

▲Air Tightness:q1 Less than or equal to 0.5 (Level 8)

▲Sound Insulation:Rw=39 (Level 4)

▲Water Tightness:△P Greater than or equal to 700(Level 6)

▲Wind Resistance:P3 Greater than or equal to 5.0 (Level 9)
